1. This equipment is mainly used for crimping and disassembling coin cells. Only one type (sealing/disassembling) die can be selected as standard for this equipment.
2.Mainly driven by an electric motor, after placing the battery into the die, pressing the motor button will cause the upper and lower dies to automatically close, crimping and forming the battery. It is used for sample preparation in laboratory battery material research and development, for making coin cells and sealing capacitors, and can also be used for small batch trial production in factories.
1. Touchscreen operation makes it easy to set parameters and has a high degree of automation.
2. Electric-driven, vibration-free battery sealing, and no leakage.
3. With different dies, it can crimp and disassemble various specifications of coin cells, achieving multi-purpose use with a single machine.
4. Precise die design ensures accurate and reliable crimping and forming, with stable and safe use.
5. Aesthetically pleasing in appearance, easy to maintain, with the advantages of small size, convenient operation, and precise forming.
Name | Parameters | Remarks |
Crimping Stroke | About 30mm | |
Crimping Efficiency | 60 seconds/piece | Reference to CR2032 |
Crimping Die | CR2032 is standard | Customized |
Dismantling Die | CR2032 is standard | Customized |
Power Supply | AC220V/50Hz， 110V/60Hz | This equipment can be used inside a glove box. |
Power | 200W | |
Equipment Dimensions | ≈L334*W257*H479mm | |
Size after Packaging | ≈L500*W340*H820mm | |
Net Weight | ≈28kg | |
Gross Weight | ≈33kg | |
Usage Site | Can be used inside the glove box, please verify if the glove box space matches the equipment's outer dimensions | |
Warranty Period | 1-year warranty, lifetime maintenance |
